Technical Overview: 7″ Foam Wiper Ball – P/N 152017
Introduction
The 7″ Foam Wiper Ball, part number 152017, is a high-performance displacement and wiping tool engineered for use in tubular operations such as cementing and fluid transition. Constructed with durable, open-cell natural rubber foam and coated with an elastomeric layer, it delivers exceptional flexibility, wiping strength, and deformation recovery under pressure.
Technical Specifications
| Parameter | Details |
|---|---|
| Part Number | 152017 |
| Nominal Pipe Size | 7.00 in (178.1 mm) |
| Actual Ball Diameter | 6.89 in (175 mm) |
| Typical Wiping Range | 5.50 in to 2.38 in (139.7 mm to 60.5 mm) |
| Minimum Restriction Tolerance | 1.000 in (25.4 mm) |
| Material Composition | High-resilience open-cell natural rubber foam |
| External Coating | Elastomeric skin (abrasion-resistant) |
| Fluid Compatibility | Water-based fluids, brines, drilling muds, spacer fluids |
| Operational Temp. Resistance | Up to 149°C (300°F) |
| Unit Weight | Approx. 0.75 kg |
Application Purposes
The 152017 model is designed for reliable wiping, fluid displacement, and separation within 7-inch tubulars and smaller internal diameters. It supports consistent and efficient push-down through vertical and horizontal sections, ensuring thorough interface control between fluids during critical wellbore operations.
Functional Features
✔️ Dimensional Recovery
Compresses through narrow restrictions (down to 1.000 in) and restores to full diameter with minimal fatigue.
✔️ Uniform Wall Contact
Expands to maintain pipe wall contact for uninterrupted wiping and flow assurance.
✔️ Superior Push Capacity
Maintains structure under differential pressure and turbulent flow conditions, driving residual fluids and materials forward.
✔️ Skin Durability
Resists tearing and abrasion, extending usable life in aggressive wellbore environments.
✔️ No Residue Left Behind
Performs without leaving behind foam fragments or degrading under high-pump-rate conditions.
Typical Operational Scenarios
- Spacer-wiper interface in cementing strings
- Pre-wipe and post-wipe ball in drill pipe sweeps
- Horizontal well wiping during displacement cycles
- Liner preparation and inner pipe integrity assurance
Conclusion
P/N 152017 – the 7″ Foam Wiper Ball – is optimized for tubular wiping and displacement performance in complex drilling and cementing sequences. Engineered for mechanical reliability, fluid transition efficiency, and resistance to deformation, it remains a trusted solution for operational reliability in the energy sector.
For inquiries, orders, or OEM cooperation, contact us.
